The COMPACT line is the most compact ozone generators on the market for this output
The new COMPACT-series is specially designed for use in commercial kitchens. The capacity ranges from 10 to 20 grams of O3 per hour.
| Compact 10 | Compact 20 | ||
| Ozone generator technique | 10 g/h | 20 g/h | |
| Ozone concentrationoutput* | Ceramic plate | Ceramic plate | |
| Operation condition | +5° to + 30 ° C (optim. 15° C) – <50% rH | ||
| Ozone output | PTFE tube connector Ø 6 mm | ||
| Oxygen flow max. | 1,5 l/min | 3,0 l /min | |
| External connections | Through connection box | ||
| Capacity control | 0/50%/100% or Regulator 0-100% in option | ||
| Electricity | 230 V / 50 Hz | ||
| Output | 490 W | 600 W | |
| Cover | Plastic | ||
| Mounting | Wall fixture | ||
| Dimensions (HxWxD) | 56 x 42 x 20 cm | ||
| Weight | 23 kg | ||
| Noise level | < 80 dB | ||
| Warranty | 1 year limited warranty |
* relative to ambient conditions
Technical changes reserved
